SKU
Pro8800WUL
Pro8800WUL - 1920 x 1200 Resolution, 5,200 ANSI Lumens, 1.07~1.71:1 Throw Ratio
Product Overview
Delivering stunning WUXGA 1920x1200 resolution and 5200 lumens of brightness, the ViewSonic® LightStream® Pro8800WUL is the ideal projector for professional installations, large venues, and business and education environments. With its 1.6x optical zoom, centered lens, vertical lens shift, and HV keystoning, the Pro8800WUL provides extreme flexibility even in the most challenging installations. Pro8800WUL includes a sleek top cover design for quick lamp and accessory access, while an intuitive PortAll® compartment accommodates additional accessories such as an HDBT receiver, wireless streaming device, or PC stick. The cable management hood hides unsightly cables, and a 4-in-1 power button serves as a central point for LED notifications. Moreover, four HDMI ports and additional audio and video ports allow for extensive connectivity to handle multiple devices without the need to switch cables. Powered by SuperColor™ technology for amazing images, and SonicExpert® technology for incredibly clear sound, the Pro8800HDL delivers professional audiovisual performance.
Bright Images in Large Spaces
Packed with 5,200 lumens and a high contrast ratio, this projector will produce bright images in large spaces with high ambient light including large boardrooms, conference halls, and auditoriums.
Vertical Lens Shift with Centered Lens
A vertical lens shift feature offers up and down adjustments of the projection lens for flexible placement in challenging installations. What’s more, a centered lens design makes this projector ideal for replacing existing centered lens installations – making it unnecessary to move or reinstall existing ceiling mounts or projection screens.
PortAll: Discreet Wireless Streaming
This projector includes ViewSonic’s exclusive PortAll® feature—a hidden compartment with an integrated and secure MHL/HDMI port that lets you discreetly stream multimedia content from an optional wireless dongle, or lets you connect to other devices via an HDMI cable. What’s more, an optional HDBT adapter lets you discreetly stream multimedia content from set-top boxes, Blu-ray players, AV receivers and more via an HDBT receiver.
4 HDMI Inputs
Four HDMI inputs allow you to connect to a variety of HD devices including gaming consoles, Blu-ray players, laptop PCs, digital cameras, and many others for a true high-definition experience.
SuperColor: Amazing Color Accuracy
SuperColor™ Technology projects images with reliable color performance, in both bright and dark environments, without sacrificing image quality.
SonicExpert® Technology
This LightStream projector is designed with ViewSonic’s proprietary SonicExpert technology that incorporates an enlarged speaker chamber and a more powerful amplifier to deliver a full 20Hz – 20Khz sound range. Dual integrated speakers captivate your audience with immersive sound.
Motorized Screen Control
With an integrated 12v trigger output, this projector can be connected to a motorized projection screen via a 12v cable. The screen will automatically lower when the projector is powered on, and automatically be raised when the projector is powered off.
4-in-1 Power Button with IR Pass-through
A centrally located, easy-to-use power button not only turns the projector on and off, but also functions as an IR receiver and control for remote devices. In addition, intuitive LED lights on the power button indicate whether any dongles are powered on within the PortAll compartment.
Extreme Mounting Flexibility
A wider optical zoom provides more mounting flexibility over a standard 1.2x optical zoom. More flexible mounting options translate to less installation hassle.
Peace of Mind
ViewSonic offers one of the industry's best overall projector warranties with 3-year limited parts and labor, 1-year lamp, and first year free Express Exchange® service* for an added value worth up to $150**.
*One year Express Exchange® Service requires product registration. **Up to $150 added value over competitive models with 1-year warranty and based on extended warranties from manufacturers and not third party warranty providers.
- Screen Size: 30 - 300 in. / 0.76 - 7.62 m
- Throw Distance: 2.26~36.25 ft / 0.69~11.05 m
- Throw Ratio: 1.07~1.71:1
- Lens: 1.6x Manual optical zoom / manual optical focus
- Light Source (watt): 370
- Light Source Life, Normal (hours): 2000
- Light Source Life, Dynamic Eco-Mode (hours): 2500
- Color Depth: 30 bits, 1.07B Color (10+10+10)
- Input Lag: 37ms
- Lens Shift: Vertical (+/-2.5 - 5%)
- Display Resolution: WUXGA (1920x1200)
- Light Source: DLP Lamp
- Display Resolution: 1920 x 1200
- Brightness (Lumens): 5,200 ANSI
- Aspect Ratio: 16:10
- Keystone: Vertical (± 30º) / Horizontal (± 30º)
- Frequency Horizontal: 15-100kHz
- Frequency Vertical: 24-120Hz
- PC Resolution (max): 1920x1200
- Mac® Resolution (max): 1920x1200
- Ethernet LAN (RJ45): 1
- 3.5mm 12V Trigger: 1
- 3.5mm Audio Out: 1
- 3.5mm Audio In: 3
- Control (RS232): 1
- HDMI 1.4 In: 3
- HDMI MHL: 1
- VGA In: 2
- VGA Out: 1
- Composite RCA Video In: 1
- S-Video In: 1
- Micro USB: 1
- RCA Audio In (L/R): 1
- 3D VESA: 1
- Wired Remote Out: 1
- 5-BNC: 1
- Internal Speakers: 10W (x2)
- Voltage: 100~240VAC (Auto Switching), 50-60Hz (universal)
- Consumption (max): 574W
- Stand-by: <0.5W
- Physical Controls: Display, Image, Power Management, Basic, Advanced, System, Information
- On Screen Display: Power, lens shift, focus, zoom, keystone/arrow keys, left/blank, right/panel key lock, menu/exit, mode/enter, source
- Temperature: 41-104º F (5 - 40º C)
- Humidity (non-condensing): 10-85%
- Kensington Lock Slot: 1
- Net (lbs): 13.89
- Gross (lbs): 23.81
- Net (kg): 6.3
- Gross (kg): 10.8
- Packaging (in.): 22.72 (W) x 21.14 (D) x 10.24 (H)
- Physical (in.): 19.55 (W) x 12.45 (D) x 5.50 (H)
- Packaging (mm): 577 (W) x 537 (D) x 260 (H)
- Physical (mm): 496.5 (W) x 316.24 (D) x 139.8 (H)
- AV Control: AMX Certified, ATEN Certified, Crestron Certified, Extron Certified, PJ Link Certified
- Regulations: EAC, TUV-S Mark(Argentina), India BIS, FCC,CE EMC, CB,CCC, ROHS, REACH, SVHC, WEEE, ErP, Mexico NOM, cTUVus, RCM, CECP
- Package Contents: Pro8800WUL projector, power cable, VGA cable, laser remote control with batteries, Quick Start Guide, ViewSonic Wizard CD (with User Guide)
- Warranty: Three-year limited warranty on parts and labor, 1-year limited warranty on lamp, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration).
- Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
- Classification: Discontinued
-
User Guides
- PRO8800WUL User Guide (Deutshland/German)
- PRO8800WUL User Guide (English)
- PRO8800WUL User Guide (Français)
- PRO8800WUL User Guide (Italiano)
- PRO8800WUL User Guide (Polski)
- PRO8800WUL User Guide (Português)
- PRO8800WUL User Guide (Spanish/Español)
- PRO8800WUL User Guide (Suomi)
- PRO8800WUL User Guide (Svenska)
- PRO8800WUL User Guide (Türkçe)
- PRO8800WUL User Guide (Русский)
- PRO8800WUL User Guide (简体中文)
- PRO8800WUL User Guide (繁體中文)
- PRO8800WUL User Guide (한국어)
-
Technical Document
- Electronics_Visual-Projectors_ViewSonic_The-ViewSonicR-PRO8800WUL-Projector(rfa)
- PRO8800WUL 3D Drawing (RFA)
- Pro8800WUL_2D_drawing(dwg)
- Pro8800WUL_2D_drawing(pdf)
- Pro8800WUL_3D_drawing(stp)
- Pro8800WUL_3D_drawing(stp)
- Projector_Pro8_PG8_cable_manager_2D_drawing(dwg)
- Projector_Pro8_PG8_cable_manager_2D_drawing(pdf)
-
