Optimized for Google Education.
Designed for Your School.

ViewBoard® IFP51 Android™ EDLA-certified Interactive Displays

Powered by the latest Android™ EDLA-certified platform, the ViewBoard® IFP51 series interactive displays provide a secure and streamlined Google Classroom experience. Users can quickly sign in, access both Google and Microsoft files, and manage devices remotely. ViewSonic’s intuitive software integrates effortlessly with Google tools to enable dynamic lessons, foster student collaboration, and streamline classroom management.

Secure by Design with Android EDLA

Stay protected with built-in Google security, data encryption, and easy management tools that help protect your network and devices.

Native Access to the Google Education Ecosystem

Integrate more useful resources and tools into your lesson plans by accessing hundreds of apps through the Google Play Store. With a single sign-on, teachers can store and share files on Google Drive, edit files in Google Docs, share spreadsheets in Google Sheets, deliver presentations on Google slides and so much more. Plus, teachers will enjoy access to the full Microsoft 365 suite (including Word, PowerPoint, Teams and more) from the Google Play Store.

Engaging Lessons with ViewSonic® Education Software

Support productivity with a suite of pre-installed ViewSonic solutions, including myViewBoard® for interactive whiteboarding, ClassSwift® for real-time classroom feedback, and ViewSonic AirSync™ for wireless content sharing.

Device Management Made Better

ViewSonic EDLA displays pair Google Workspace enterprise tools with ViewSonic Manager for complete control. IT teams can manage apps, enforce policies, adjust hardware settings, and send campus-wide alerts, all from a single platform that simplifies and streamlines device management across the school.

Enhanced Multi-User Login

In today’s dynamic classrooms, a single interactive panel can be used by multiple teachers throughout the day. ViewSonic’s EDLA-certified ViewBoard displays come with a custom launcher that simplifies this process through Enhanced Multi-User Login. Teachers can easily switch between guest mode and their personalized accounts, allowing them to access their files (such as Google Drive and Slides) across different classrooms. This feature reduces the need for frequent IT support and enhances security with single sign-on and QR code login options.

Immersive Audio for Maximum Engagement

A powerful 70W front-facing soundbar with a built-in subwoofer ensures crystal-clear sound throughout the classroom. The integrated beamforming microphone array with noise cancellation captures voices from up to 8 meters away, making it ideal for remote teaching and lesson recordings.

High-Performance Multitasking

The octa-core CPU and 16GB RAM deliver smooth and efficient multitasking, enabling teachers to run multiple applications simultaneously without lag.

Featured Products

IFP5551

55” Android™ EDLA ViewBoard Interactive Display

IFP6551

65” Android™ EDLA ViewBoard Interactive Display

IFP7551

75” Android™ EDLA ViewBoard Interactive Display

IFP8651

86” Android™ EDLA ViewBoard Interactive Display

IFP9851

98” Android™ EDLA ViewBoard Interactive Display

IFP5551
IFP6551
IFP7551
IFP8651
IFP9851
Display
Panel Size
55"
65"
75"
86"
98"
Type
TFT LCD module with DLED backlight
Display Area (mm)
1209.60mm(H) x 680.40mm(V)
1428.48mm(H) x 803.52mm(V)
1650.24mm(H) x 928.26mm(V)
1895.04mm(H) x 1065.96mm(V)
2158.85mm(H) x 1214.35mm(V)
Aspect Ratio
16:9
Native Resolution
UHD 3840x2160(Pixels)
Colors
1.07G colors (8bit+2bit FRC)
Brightness
400nits (with CG) (Typical)
Contrast Ratio
1000:1 (minimum) / 1200:1 (typical) / 5000:1 (max. with DCR enabled)
Response Time
6.5ms (Typ.)
6.5ms (Typ.)
6.5ms (Typ.)
8ms (Typ.)
6.5ms (Typ.)
Viewing Angles
H = 178, V = 178 (Typ.)
Backlight Life
5,0000 hours
Surface Treatment
Anti-glare, anti-fingerprint, 9H Pencil hardness / 3.2mm thickness
Haze
25%
Bezel (L/R/T/B)
17.3/17.3/26.9/50.8
14.6/14.6/25.5/50
14.6/14.6/25.5/50
14.6/14.6/25.5/50
17.5/17.5/27.8/52.2
Orientation
Landscape
Platform
Processor
Rockchip RK3576
RAM
16 DDR4
Storage
128GB eMMC
Touch
Type/ Tech
IR Recognition
Touch Point
Windows/Android /EDLA: 50 points | All Other Channels: 20 points
Response Time
5ms
Pen Tips Size
2mm/8mm
Palm Rejection
Yes
CG +OC Bonding
Zero Bonding
INPUT
HDMI-IN
*4(Front*2 + Rear*2)
All HDMI/IN supports HDMI 2.1, CEC1.4 HDCP 2.2 3840x2160P @60Hz
HDMI 1 supports ARC
RGB / VGA
1 (1080@60HZ)
DisplayPort
1 (DP 1.2)
Audio
1 (3.5mm phone jack)
RS232
1
SD/SDHC
TF Card Slot(Micro SD)
OPS
1 (complies with Intel 80-pin standard)
OUTPUT
HDMI-OUT
1( HDMI 2.1,HDCP 1.x, not support CEC, ARC)
Audio
1 (Line out)
SPDIF
1 (Optical)
LAN
RJ45
1 in 1 out (10M/100M/1000Mbps) (USB Type-C 10/100, Android & PC 10/100/1000)
USB
Type A
REAR x 1 (USB 2.0 for system update)
REAR x 2 (USB 3.2 Gen 1) all support Smart
FRONT x 2 (USB 3.2 Gen 1) all support Smart
Type B
FRONT x 1 (USB 3.2 Gen 1) REAR x 1 (USB 3.2 Gen 1)
Type C
Front x1 (USB 3.2 Gen 1+ PD 65W + DP-in 1.2 + 100M Ethernet)
Rear x1 (USB 3.2 Gen 1 + PD 15W + DP-in 1.2 + 100M Ethernet)
Top x1 (USB 3.2 Gen 1+ PD15W to support Camera mounting)
<PD reduces to 15W with OPS plugged-in>
SPEAKERS
Speaker: 25W x 2 + Subwoofer: 20W x 1
Microphone Array
8-array microphone
Embedded OS
Android 14(EDLA)
NFC Built-In
yes
Light Sensor
yes
Pen Sensor
yes
DIMENSIONS
49.99x31.08x3.3
58.6x35.99x3.36
67.29x40.85x3.36
77.05x46.36x3.36
87.39x52.1x3.35
WEIGHT
57.01
76.15
101.54
128.88
184.53
