Product Overview

With future-proof connectivity and advanced ergonomics, the ViewSonic^® VG2453 is a productivity-boosting monitor perfect for corporate, government, and education environments. Designed with SuperClear^® IPS panel technology for wide-angle viewing and incredibly vivid colors, this monitor also features a 3-sided frameless design for a seamless viewing experience in multi-monitor setups. For maximum comfort and a customized fit, a robust fully ergonomic stand gives you tilt, pivot, swivel, and height-adjustable options. In addition, VDI client endpoints can be easily attached to the stand’s integrated client mount, saving desktop space and minimizing cable clutter without interfering with ergonomic functionality. Extensive connectivity options include VGA, HDMI, DisplayPort, and Mini DisplayPort so that you can connect to a variety of HD and analog devices – today and tomorrow.

Overview

Awards

Specifications

Screen Size: 24
Viewable Area (in.): 23.8
Panel Type: IPS
Display Resolution: 1920 x 1080
Static Contrast Ratio: 1,000:1
Dynamic Contrast Ratio: 20,000,000:1
Light Source: WLED
Brightness: 250 cd/m2
Colors: 16.7M
Color Space Support: 6-bit+A-FRC
Aspect Ratio: 16:9
Response Time (Typical GTG): 14ms
Response Time (GTG w/OD): 7ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30,000
Panel Surface: Anti-glare, Hard coating (3H)
PC Resolution (max): 1920 x 1080
USB 3.0 Type A: 2
USB 3.0 Type B: 1
3.5mm Audio In: 1
3.5mm Audio Out: 1
VGA: 1
HDMI 1.4 In: 1
DisplayPort: 1
Mini DisplayPort: 1
Internal Speakers: 2-watt (x2)
Eco Mode (Conserve): 15W
Eco Mode (optimized): 19W
Consumption (typical): 21W
Consumption (max): 45W
Voltage: AC 100-240V (universal), 50-60Hz
Stand-by: 0.5W
Cable Organization: No
Kensington Lock Slot: 1
Physical Controls: 1,2, Up, Down, Power
On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Advanced Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)
Temperature: 32-104º F (0 - 40º C)
Humidity (non-condensing): 20-90%
VESA Compatible: 100 x 100 mm
Analog Sync: Separate Sync / Composite Sync / Sync on Green
Digital Sync: TMDS, PCI-E
Height Adjust: 135 mm / 5.3 in
Swivel: 360º
Pivot (Right/Left): 90º / 0º
Tilt (Forward/Back): 5º / 20º
Net (lbs): 11.4
Net Without Stand (lbs): 6.9
Gross (lbs): 14.9
Net (kg): 5.2
Net Without Stand (kg): 3.1
Gross (kg): 6.8
Packaging (in.): 27.1 x 16.3 x 7.6
Physical (in.): 21.3 x 20.4 x 9.2
Physical Without Stand (in.): 21.3 x 16.3 x 1.8
Packaging (mm): 688 x 415 x 193
Physical (mm): 540 x 518 x 233
Physical Without Stand (mm): 540 x 324 x 46
Regulations: cULus, FCC-B, ICES003, Energy Star 7.0, EPEAT, MX-CoC, Mexico Energy
Package Contents: LCD Display, Power Cable (1.5m), Mini DP to DP Cable (1.5m), USB3.0 Upstream Cable (1.5m), Quick Start Guide, ViewSonic Wizard CD-ROM
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Classification: Discontinued

Screen Size: 24
Viewable Area (in.): 23.8
Panel Type: IPS
Display Resolution: 1920 x 1080
Static Contrast Ratio: 1,000:1
Dynamic Contrast Ratio: 20,000,000:1
Light Source: WLED
Brightness: 250 cd/m2
Colors: 16.7M
Color Space Support: 6-bit+A-FRC
Aspect Ratio: 16:9
Response Time (Typical GTG): 14ms
Response Time (GTG w/OD): 7ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30,000
Panel Surface: Anti-glare, Hard coating (3H)

PC Resolution (max): 1920 x 1080

USB 3.0 Type A: 2
USB 3.0 Type B: 1
3.5mm Audio In: 1
3.5mm Audio Out: 1
VGA: 1
HDMI 1.4 In: 1
DisplayPort: 1
Mini DisplayPort: 1

Internal Speakers: 2-watt (x2)

Eco Mode (Conserve): 15W
Eco Mode (optimized): 19W
Consumption (typical): 21W
Consumption (max): 45W
Voltage: AC 100-240V (universal), 50-60Hz
Stand-by: 0.5W

Cable Organization: No
Kensington Lock Slot: 1

Physical Controls: 1,2, Up, Down, Power
On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Advanced Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)

Temperature: 32-104º F (0 - 40º C)
Humidity (non-condensing): 20-90%

VESA Compatible: 100 x 100 mm

Analog Sync: Separate Sync / Composite Sync / Sync on Green
Digital Sync: TMDS, PCI-E

Height Adjust: 135 mm / 5.3 in
Swivel: 360º
Pivot (Right/Left): 90º / 0º
Tilt (Forward/Back): 5º / 20º

Net (lbs): 11.4
Net Without Stand (lbs): 6.9
Gross (lbs): 14.9

Net (kg): 5.2
Net Without Stand (kg): 3.1
Gross (kg): 6.8

Packaging (in.): 27.1 x 16.3 x 7.6
Physical (in.): 21.3 x 20.4 x 9.2
Physical Without Stand (in.): 21.3 x 16.3 x 1.8

Packaging (mm): 688 x 415 x 193
Physical (mm): 540 x 518 x 233
Physical Without Stand (mm): 540 x 324 x 46

Regulations: cULus, FCC-B, ICES003, Energy Star 7.0, EPEAT, MX-CoC, Mexico Energy
Package Contents: LCD Display, Power Cable (1.5m), Mini DP to DP Cable (1.5m), USB3.0 Upstream Cable (1.5m), Quick Start Guide, ViewSonic Wizard CD-ROM
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Classification: Discontinued
