PX706HD - 1080p Short Throw Gaming Projector with 3000 Lumens, Low Input Lag and USB C
- Reduced Input Latency
- Bright Images in Any Environment (3,000 Lumens)
- Large Images in Small Spaces
- USB Type-C for Video and Power
- SonicExpert® Technology
Product Overview
For convenient big screen gaming and entertainment, the ViewSonic® PX706HD projector delivers huge images in small spaces. With a short throw lens, this projector can be placed just a few feet away from a wall or screen, and project an immersive 100” image – making it perfect for big gaming sessions in smaller rooms. 3,000 lumens of brightness and Full HD 1920x1080 resolution provide vivid, ultra-sharp images and graphics, while an ultra-low input latency ensures faster frame-by-frame action and smooth gameplay without delay. What’s more, Full HD 3D compatibility lets you enjoy 3D movies and games, while an internal speaker delivers room-filling sound for an immersive audiovisual experience.
Reduced Input Latency
Ideal for intense action-packed gaming, this projector delivers smooth images without delay. Its ultra-low 16ms input latency provides faster frame-by-frame action.
Bright Images in Any Environment
Packed with 3,000 lumens and a high contrast ratio, this projector produces bright images in nearly any environment.
Large Images in Small Spaces
With a short throw lens, this projector can be placed just a few feet from a wall or screen and project images up to 100".
USB Type-C for Video and Power
A USB Type-C port delivers fast data, audio, video and quick charging over a single cable.*
*The projector's power adapter must be plugged in for USB Type-C charging. When the projector is not plugged in and operating on battery power alone, it can still play content from a mobile device connected via USB Type-C, but it cannot charge the mobile device. Please ensure the host device supports video transmission.
SonicExpert® Technology
This projector is designed with ViewSonic’s proprietary SonicExpert® technology that incorporates an enlarged speaker chamber and a more powerful amplifier to deliver a full 20Hz – 20Khz sound range. An integrated speaker captivates your audience with immersive sound.
Jul 2018
| Light Source | DLP Lamp |
|---|---|
| Display Resolution | Full HD (1920x1080) |
| Display Resolution | 1920 x 1080 |
| Brightness (Lumens) | 3,000 ANSI |
| Screen Size | 60 - 120 in. / 1.5 - 3.0 m |
| Throw Distance | 3.0 - 7.2 ft / 0.9 - 2.2 m |
| Throw Ratio | 0.69-0.83 |
| Keystone | Vertical digital keystone correction (± 20º) |
| Lens | 1.2x optical zoom |
| Light Source (watt) | 240 |
| Light Source Life, Normal (hours) | 4000 |
| Light Source Life, Dynamic Eco-Mode (hours) | 15000 |
| Color Depth | 1.07B Color (R/G/B 10bit) |
| Dynamic Contrast Ratio | 22,000:1 |
| Aspect Ratio | 16:9 |
| Input Lag | 37ms |
| Frequency Horizontal | 15K~102KHz |
| Frequency Vertical | 23~120Hz |
| PC Resolution (max) | 1920 x 1080 |
| PC Resolution (min) | 640 x 480 |
| Mac® Resolution (max) | 1920 x 1080 |
| Mac® Resolution (min) | 640 x 480 |
| USB 3.1 Type C | 1 |
| 3.5mm Audio Out | 1 |
| 3.5mm Audio In | 1 |
| Control (RS232) | 1 |
| HDMI 1.4 In | 2 |
| VGA In | 1 |
| Composite RCA Video In | 1 |
| Mini USB | 1 |
| Internal Speakers | 5W (x1) |
| Voltage | 100-240V+/- 10%, 50/60Hz AC |
| Consumption (typical) | 310W |
| Stand-by | <0.5W |
| Physical Controls | Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, mode/enter, auto, source |
| On Screen Display | Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality) |
| Temperature | 32-104º F (0 - 40º C) |
| Humidity (non-condensing) | 0-90% |
| Kensington Lock Slot | 1 |
| Net (lbs) | 6.0 |
| Gross (lbs) | 8.4 |
| Net (kg) | 2.7 |
| Gross (kg) | 3.8 |
| Packaging (in.) | 14.4 x 7.4 x 11.8 |
| Physical (in.) | 11.5 x 4.5 x 8.7 |
| Packaging (mm) | 365.0 188.0 x 300.0 |
| Physical (mm) | 293.0 x 115.0 x 220.0 |
| Regulations | FCC, cTUVus, ROHS |
| PACKAGE CONTENTS | PX706HD projector, power cable, USB Type C cable, remote control, Quick Start Guide |
| Warranty | Three-year limited warranty on parts and labor, 1-year limited warranty on lamp, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration). |
| Recycle/Disposal | Please dispose of in accordance with local, state or federal laws. |
