PX701HDH - 1080p Home Theater Projector with 3500 Lumens and Powered USB
- Bright Images in Any Environment
- Long Lamp Life
- Vertical Lens Shift
- Cloud-based Color Profile Exchange
- SuperColor: Amazing Color Accuracy
Product Overview
Ideal for both home entertainment and office use, the ViewSonic® PX701HDH delivers stunning Full HD images for versatile projection. With 3,500 ANSI lumens, this high-brightness projector delivers clear pictures even in brightly lit rooms. What’s more, an energy-saving SuperEco™ feature reduces power consumption and extends the lamp life by up to 20,000 hours,* effectively reducing lamp replacement and maintenance costs. A cloud-based vColorTuner™ feature allows users to customize and save color profiles, while exclusive SuperColor™ technology offers a wide color gamut for beautiful image production in nearly any environment. Dual HDMI inputs and USB power supply delivers flexible connectivity options for gaming, movies, wireless dongles, and more.
Bright Images in any Environment
Packed with 3,500 lumens and a high contrast ratio, this projector produces bright images in nearly any environment.
*The image contained herein is simulated to reflect an image under different resolution (or scheme) for demonstration purposes only, and may not be the actual image displayed from the product.
An energy-saving SuperEco™ feature reduces power consumption and extends the lamp life by up to 20,000 hours.*
*Lamp life may vary based on actual usage and other factors.
Cloud-Based Color Profile Exchange
A vColorTuner feature allows you to create and update your own color profile, then share this profile with other users. You can also download color profiles created by others for use on your own projector. This functionality lets you fine-tune and customize the color settings of your projector to best fit your personal preferences.
SuperColor: Amazing Color Accuracy
ViewSonic’s proprietary SuperColor™ Technology features an exclusive 6-segment color wheel and dynamic lamp control capabilities, providing a wide color range and stunningly beautiful images.
| Light Source | DLP Lamp |
|---|---|
| Display Resolution | Full HD (1920x1080) |
| Display Resolution | 1920 x 1080 |
| Brightness (Lumens) | 3,500 ANSI |
| Screen Size | 30 - 300 in. / 0.76 - 7.62 m |
| Throw Distance | 1m~10.96m (100"@3.32m) |
| Throw Ratio | 1.5-1.65 |
| Keystone | Vertical (+/- 40°) |
| Lens | 1.1x optical zoom |
| Light Source (watt) | 203 |
| Light Source Life, Normal (hours) | 5000 |
| Light Source Life, Dynamic Eco-Mode (hours) | 20000 |
| Color Depth | 1.07 Billion Colors |
| Dynamic Contrast Ratio | 12,000:1 |
| Aspect Ratio | 16:9 |
| Input Lag | 37ms |
| Frequency Horizontal | 15K-102KHz |
| Frequency Vertical | 23-120Hz |
| PC Resolution (max) | 1920 x 1200 |
| PC Resolution (min) | 640 x 480 |
| Mac® Resolution (max) | 1920 x 1200 |
| Mac® Resolution (min) | 640 x 480 |
| USB 2.0 Type A | 1 |
| 3.5mm Audio Out | 1 |
| 3.5mm Audio In | 1 |
| Control (RS232) | 1 |
| HDMI 1.4 (with HDCP 1.4) | 2 |
| Internal Speakers | 10W (x1) |
| Voltage | 100-240V+/- 10%, 50/60Hz AC |
| Consumption (typical) | 300W |
| Stand-by | <0.5W |
| Physical Controls | Keypad, Power key |
| On Screen Display | Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality) |
| Temperature | 32–95º F (0 - 35º C) |
| Kensington Lock Slot | 1 |
| Net (lbs) | 5.7 |
| Gross (lbs) | 8.3 |
| Net (kg) | 2.6 |
| Gross (kg) | 3.8 |
| Packaging (in.) | 16.3 x 6.6 x 11.7 |
| Physical (in.) | 12.2 x 4.4 x 8.7 |
| Packaging (mm) | 415.0 x 168.0 x 297.0 |
| Physical (mm) | 312.0 x 108.0 x 222.0 |
| Regulations | cTUVus |
| PACKAGE CONTENTS | PX701HDH projector, power cable, remote control, Quick Start Guide |
| Warranty | Three-year limited warranty on parts and labor, 1-year limited warranty on lamp, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration). |
| Recycle/Disposal | Please dispose of in accordance with local, state or federal laws. |
