55" 4K Commercial Display with 350 cd/m² Brightness, 16/7 Operation, HDMI, USB-C, Content Sharing, Remote Management | CDE5514

Name: 55" 4K Commercial Display with 350 cd/m² Brightness, 16/7 Operation, HDMI, USB-C, Content Sharing, Remote Management | CDE5514
SKU: CDE5514
Price: 1229.99 USD

Comparison Sheet (PRG)

| Datasheet | Media

Add to Compare

Product Overview

The ViewSonic CDE14 series is a high-performance 4K display purpose-built for Corporate Offices, Higher Education, and the Public Sector. Featuring a 25% high-haze anti-glare coating and a 350-nit "sweet spot" for eye comfort, it ensures reflection-free clarity in Retail Boutiques and Professional Services. This series eliminates technical friction with Single-Cable USB-C connectivity, AirSync™ wireless casting, and a secure Android 14 platform. Unlike standard 16/7 displays that require expensive licenses or proprietary hardware, the CDE14 offers a Certified Pro-AV Ecosystem (Crestron, Extron, Q-SYS) and includes ViewSonic Manager™ Basic for free, centralized fleet control. With Intelligent Signal Failover and a fast "Warm Boot" startup, your communications remain active and efficient. Eco-certified and future-proof, the CDE5514 delivers a premium, secure experience with a significantly lower total cost of ownership than leading competitors.

Overview

Awards

Specifications

OS: Android 14 AOSP
GPU: ARM Mali-G57 MC1
CPU: MT9681 (ARM Cortex-A73 x4)
Memory: 4GB DDR4
Storage: 32GB
HDMI 2.1: 480i, 480p,720p,1080i,1080p, 4K@60Hz
HDMI Out: 4K@60Hz
USB-C: 480p, 576p, 720p, 1080p, 4K@60Hz
Speaker Position: Bottom
Internal Speakers: 10W (x2)
HDMI 2.1 In: 3
3.5mm Audio Out: 1
SPDIF: 1
USB 2.0: 2
USB Type C: 15W x 1
RS232: 1
Ethernet LAN (RJ45): 1
Voltage: 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz
Consumption (max): 149.3W
Consumption (typical): 60.3W
Stand-by: <0.5W
Screen: H Position, V Position, Clock, Clock phase, Zoom mode, Auto adjust, Screen reset
Picture: Brightness, Contrast, Sharpness, Tint, Color, Color temperature, Picture Mode, Overscan, RGB Range, Blue Light Filter, Noise reduction, Gamma Set, Picture reset
Audio: Balance, Treble, Bass, Volume, Maximum volume, Minimum volume, Mute, Volume Control, SPDIF Sync, SPDIF Volume (Line out), Audio reset
Time: Off timer, Date and time, Schedule, Slideshow interval, OSD turn off, Information OSD, Switch on Delay, Time Reset
Tiling: Enable, H monitors, V monitors, Position, Frame Comp.
PIP: PIP Mode, PIP Size, PIP Position, PIP Change, PIP Source, PIP Audio, PIP Reset
Advanced Options: Panel Saving, Power Save, Power LED light, Boot on source, Boot On logo, Auto Signal Detection, No Signal Standby, HDMI with One Wire, HDMI Version, USB cloning, USB Auto Play, Switch on state, WOL, Monitor ID, Language, Factory Reset, Advanced Reset
About: Heat status, Model name, Serial No, Operation hours, SW version
Temperature: 32-104º F (0 - 40º C)
Humidity (non-condensing): 20-80%
Altitude: 0 - 3000m above sea level
Net (lbs): 28.55
Gross (lbs): 39.64
Net (kg): 13.0
Gross (kg): 18.0
Packaging (in.): 52.44 x 33.03 x 6.14
Physical (in.): 48.54 x 27.7 x 2.81
Packaging (mm): 1332 x 839 x 156
Physical (mm): 1233 x 703.5 x 71.4
Screw Size: M6
Screw Length (mm): 12
VESA Compatible: 400 x 400 mm
AV Control: AMX Certified, Extron Certified, Crestron Connected
Warranty: Three-year limited warranty on parts, labor and backlight
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Package Contents: CDE5514 Commercial Display, Remote control with batteries, Quick Start Guide, Power cable (3m), HDMI Cable (3m), Wall Mount Screws (x4), AAA battery (x2) and RS232 adapter
Regulations: cTUus, FCC, Energy Star 8.0, RoHS
Wifi: VB-WIFI-005 adapter, 802.11AX + Bluetooth 5.2
Screen Size: 55
Viewable Area (in.): 55
Orientation: Landscape
Colors: 1.07B
Color Space Support: 8 bit + FRC
Backlight Life (Hours): 30,000
Bezel Width (in.): 0.39
Bezel Width (mm): 9.9
Viewing Angles: 178º horizontal, 178º vertical
Operation Rating: 16/7
Display Resolution: 3840 x 2160
Response Time (Typical GTG): 8ms
Aspect Ratio: 16:9
Dynamic Contrast Ratio: 2,000:1
Panel Surface: Anti-Glare type, Hard-coating (3H), Haze 25%
Light Source: DLED
Brightness: 350 cd/m2
Static Contrast Ratio: 1,200:1
Panel Type: ADS
Refresh Rate: 60Hz
