Product Overview

PJD8353S and PJD8653WS IR Optional Interactive Module IR CAMx1 Penx2, White

LANGUAGE: N/A
Regulations: N/A
Package Contents: 1. Pen with battery x 2 <br>2. Quick Start Guide (one sheet version), x1* <br> 3. Software CD <br>4. IR camera <br>5. 4.5 M usb line
Warranty: N/A
OTHER: N/A
Classification: Discontinued
Temperature: 10°~40°C / 64°~104°F
Humidity: 10~85%, Non-Condensation
Altitude: 0~6,000 ft, operational up to 10,000 ft at reduced reliability and performance
Physical: 117(W) x 98(D) x 46(H) mm 4.6”(W) x 3.86”(D) x 1.69”(H)
Packaging: 245(W) x 166(D) x 63(H) mm 9.65”(W) x 6.54”(D) x 63(H)
Net (kg): 0.45Kg (1 lb)
Gross: 0.59Kg (1.3 lb)
Sensor Size: 1/4“ CMOS
Calibration: Auto Calibration
Throw Ratio: 0.35
Memory: 8M
IR Band: 940 nm
Power Consumption: 150mA
Multi-Touch: 2-touch points
Projection Image Distance/Size: 60" to 100"
Detect Frame Rate: 60 fps (16.6ms)
Driver Install: Auto Installation
Resolution: 2560 x 1920 (Interpolated); 640 x 480 (Native)
Light Source Wavelength: IR (940 nm)
Pen Cap: AAA Battery (alkaline) x 2
Weight: 50g (with Batteries)
Dimensino (L x W): 160 mm (L) x 11.5mm (Diameter)
Driving Current: 110mA (Max.)
Material of Body: Metal

PJ-PEN-003
