VPCF5-W33-G1-2A

Slot-in PC for ViewBoard® Interactive Display

Windows 11 Pro
An ideal integrated solution for ViewBoard® interactive displays & presentation displays
Powered by Intel® 12th generation processors with embedded TPM2.0
DP1.4 port supports up to 5K resolution at 60Hz, delivering clear and detailed content
Enhanced system stability, security, & thermal control

Yêu cầu bán hàng Chia sẻ

BỘ SƯU TẬP

TỔNG QUÁT

Seize the power to get more done by syncing your ViewBoard® Interactive Displays and Presentation Displays with the ViewSonic VPCF5-W33-G1-2A slot-in PC. Experience exceptional performance with Intel® 12th generation processors, 8GB DDR4 memory, and 256GB SSD storage, allowing you to breeze through any task at hand. Enhance productivity with dual-band WiFi, Bluetooth 5.2, and a range of ports, including 4K HDMI, 5K DP, USB 3.1, and Gigabit LAN RJ45 for faster workflows.

Tap Into a Productivity Powerhouse

Boost your interactive whiteboard with remarkable power and lightning-fast speed from the Intel® 12th Gen Core™ processor, allowing you to zip through tasks effortlessly. With Intel® WiFi 6 and Bluetooth 5.2 integration, experience ultra-fast and versatile connectivity.

Uninterrupted Performance

Use the interactive display without worrying about sudden disruptions. Built with FinchGuard, a Watchdog timer software, the VPCF5-W33-G1-2A intuitively detects and recovers from system malfunctions seamlessly, maximizing productivity.

Quiet Efficiency with Advanced Thermal Control

Equipped with a thermal control circuit and noise reduction capabilities, the device's fan dissipates heat efficiently while maintaining quiet acoustics under 35 decibels, ensuring a more conducive and longer use.

Unparalleled Visual Clarity

Experience exceptional visual performance with HDMI 1.4 and DP 1.4 output ports, respectively supporting up to 4K resolution at 24Hz and 5K resolution at 60Hz, offering flexibility for various resolutions.

Boot Up with Total Security

Prevent malicious software and unwanted operating systems from loading during startup with the optional Secure Boot in the BIOS settings. This feature stops existing errors from loading and to prevent unauthorized personnel from accessing PC settings.

Built-in myViewBoard Software

The VPCF5-W33-G1-2A seamlessly integrates with myViewBoard software, providing users with a robust whiteboarding solution featuring a wide range of capabilities, including file import, drag-and-drop content from the internet, and cloud integration.

Thông số kỹ thuật

Phần mềm
Hệ điều hành: Windows 11 Pro
Nhân
CPU: Intel Gen12th core i5 CPU or later Gen. CPU
Đồ họa: Intel® Iris® Xe Graphics* (DP Supports up to 8K@30Hz, HDMI Supports up to 3840x2160@30Hz)
Kỉ niệm
Kiểu: DDR4
Sức chứa: 8GB

Kho lưu trữ
Kích thước: M.2 SSD
Sức chứa: 256GB
Giao diện: PCIE
INPUT
MIC (Micrô): MIC-In&Line-Out two in one connector
OPS Standard: 80 PIN x1 (HDMI 2.0 4K@60Hz, DP 5K@60Hz, USB3.0 x1 + USB2.0 x2, DC 12-19V)
OUTPUT
HDMI: x1 (Max 3840x2160@30Hz)
Âm thanh: MIC-In&Line-Out two in one connector
LAN
RJ45: x1 (RJ45 10/100/1000M)
Không dây / Bluetooth
Không dây / Bluetooth: Intel® Wi-Fi 6 AX101
WIFI 6 802.11 ax + BT5.2
USB
Loại A: USB 3.1 x 2 / USB 2.0 x 2
Loại C: USB 3.1 Gen2 x 1 (Data Only)
Power
Vôn: DC 19 V/ 4.74A
Sự tiêu thụ: Max 90 W
OPERATING CONDITIONS
Nhiệt độ (º C): 0℃ ~ 40℃(working)
Độ ẩm: 20% ~ 80% RH
Non-Condensing(working)
KÍCH THƯỚC (Rộng x Cao x Dày)
Kích thước (inch / mm): 7.87 x 4.68 x 1.18 in / 200 x 119 x 30 mm
Bao bì (inch / mm): 10 x 7.72 x 2.76 in / 254 x 196 x 70 mm
WEIGHT
Khối lượng tịnh (lb / kg): 1.54 lb / 0.7 kg
Tổng (lb / kg): 1.54 lb / 3.4 kg
NỘI DUNG GÓI
NỘI DUNG GÓI: 1. Quick Start Guide(With Compliance Statement )
2. Screws x 2
3. Antenna x 2
Disclaimer
* Intel® Iris® Xe Graphics in this model is an integrated GPU. Actual graphics performance may vary depending on the system-memory configuration. For optimal results, a dual-channel memory setup is recommended. When only single-channel memory is used, certain graphics features may be unavailable and overall GPU performance may differ.
