VA703b

43 cm / 17" VA SERIES LCD MONITOR WITH 5MS VIDEO RESPONSE

COLORS
Black
LCD
Tip: 43 cm / 17" TN colour TFT active matrix SXGA LCD
Rată de contrast: 700:1 (typ.)
Unghiuri de vizualizare: 160° horizontal, 160° vertical (at 10:1)

170° horizontal, 170° vertical (at 5:1)
Luminozitate: 300cd/m² (typ.)
Display Area: 33.8cm horizontal x 27.0cm vertical; 43.2cm diagonal
Optimum Resolution: 1280 x 1024@60Hz
Timp de răspuns: 5ms (off-on-off) (typ.)
Sursă de lumină: Long life, 50000 hrs. (min.)
Panel Surface: Anti-glare (3H)
Pixel Pitch: 0.264mm
Colour Support: 16.7M colours supported (6-bit + 2-bit FRC)
Pixel Clock: 135MHz
COMPATIBILITY
PC: VGA up to 1280 x 1024 non-interlaced (@60Hz preferred)
Mac®: Power Mac™ up to 1280 x 1024 non-interlaced (@60Hz preferred)

DIMENSIONS
Physical With Stand: 379 x 400 x 210
CONȚINUT PACHET
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
CONNECTOR
Analogue: 15-pin mini D-Sub (attached cable)
Putere: 3-pin AC plug (CEE22)
POWER
Voltaj: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consum: <36 watt (max.), <1 watt in power save mode
CONTROLS
Basic: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup
menu (language [English, Finnish, French, German, Italian, Japanese, Spanish, Simplified Chinese, Traditional Chinese], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
OPERATING CONDITIONS
Temperatură: 0°C – 40°C
Umiditate: 10% – 90% (non-condensation)
WEIGHT
Net With Stand: 3.6kg
Greutate: 4.8kg
VIDEO INPUT
Frequency: Fh: 30–82kHz, Fv: 50–75Hz
Sync: H/V separate (TTL)
Analogue: RGB analogue (0.7 Vp-p, 75 ohm)
POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR standards
SECURITY
Kensington® security port
VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
ERGONOMICS
Înclinare: Down 5°, Up 20°
