LB-WIFI-001
Dual Band Wireless Module for ViewBoard® IFP50 Series
PANORAMICA
The ViewSonic LB-WIFI-001 wireless module delivers fast wireless internet connection for ViewSonic ViewBoard® interactive displays (IFP50 series). It supports dual frequency 2.4GHz and 5.0GHz bandwidth, along with the newest 802.11AC standard to provide up to 433Mbps transmission.Dual Band Wireless Support
This device offers a 2.4GHz and 5GHz dual band wireless transmission that smoothly streams multimedia content such as videos and images, without any delays. The 2.4GHz frequency is perfect for web browsing and presentations, while the wider bandwidth of 5GHz is perfect for streaming high-quality videos and games.
2.4GHz and 5GHz, smooth playback
Faster Wi-Fi
Wireless 802.11 AC delivers incredibly fast Wi-Fi performance with internet speeds of up to several gigabits per second.
802.11AC wireless network
SPECIFICHE
- CoreCPU: Realtek RTL8821AU-VS
- ArchiviazioneInterfaccia: USB 2.0
- Wireless / BluetoothWifi Standard: 802.11 a/b/g/n/ac,
2.4G & 5G(5150MHz-5250MHz & 5725MHz-5825MHz), Up to 433.5Mbps
Bluetooth: Support 2.1/3.0/4.0 BLE
- AlimentazioneVoltaggio: 5V DC
Consumo: < 2.5W - OPERATING CONDITIONSTemperatura (º C): 32°F to 104°F (0°C to 40°C)
Umiditá: 10% ~ 90% non-condensing - DIMENSIONS Prodotto (inch / mm): 3.90x0.43x3.03 in / 99x11x77mm
Imballaggio (inch / mm): 3.54x0.63x6.18 in / 90x16x157mm - WEIGHTProdotto (lb / kg): 0.07lb / 30g
Imballaggio (lb / kg): 0.18lb / 80g - REGULATIONSFCC, FCC ID, IC ID, CE, RCM
- Contenuto della confezione1. LB-WIFI-001
2. QSG
