NMP711-P10

Slot-in PC

Core
CPU: Intel i5-4440 / i5-4460 / i5-4590
Graphics: Integrated Intel HD 4600
Total Available Graphics Memory: 1700MB Max Resolution up to 4K2K@24Hz
Memory
Type: 204-pin DDR3 SO-DIMM x 2
Capacity: 4GB (up to 16GB)
Software
Operating System: Windows 10 Pro 64 bit

Storage
Dimension: 2.5"
Capacity: 500GB 5400rpm (up to 1TB)
Interface: SATA2 6GB/sec
INPUT
MIC(Microphone): x1
OUTPUT
RGB / VGA: x1
DisplayPort: Mini DisplayPort x1
HDMI: x1
Audio: x1 (Line Out)
LAN
RJ45: x1 (Integrated 10/100/1000M Adaption)
Wireless / Bluetooth
2.4G & 5G / Bluetooth 4.0
USB
Type A: x5 (2.0), x2 (3.0)
Bundle Software
ViewBoard 2.1
Compatible Models
CDE5560T, CDE6560T, CDE7060T, CDE8451-TL, CDE5561T, CDE6561T, CDE7061T, CDE8452T
Power
Voltage: AC 110-240V 1A
Consumption: 89W
DIMENSIONS (W x H x D)
Physical (inch / mm): 9.76 x 8.54 x 1.3 / 248 x 217 x 33
WEIGHT
Net (lb / kg): 4.34 / 1.97
PACKAGE CONTENTS
DVD / Antenna
