VPC37-W53-G1
Slot-in PC for ViewBoard®
- Windows 11 Pro
- Ideal Integrated Solution for ViewBoard® Interactive Displays & Presentation Displays
- Powerful Intel® 12th Core Processors embedded TPM2.0
- Improved System Stability, Security, & Thermal Control
產品介紹
Seize the power to get more done when you sync your ViewBoard® interactive displays and Presentation Displays with the ViewSonic VPC37-W53-G1 slot-in PC. Integrated with exceptional performance from Intel® processors, 16GB DDR4 memory, and 256GB of SSD storage, the experience enhances computing performance to breeze through complex classes and collaborations. Plug into pure productivity with dual-band WiFi, Bluetooth 5.1, and a range of ports, including 4K HDMI, DP1.4, USB 3.0, and Gigabit LAN RJ45 for faster workflows.Tap into a productivity powerhouse
Boost the interactive whiteboard with remarkable power and lightning-fast speed from Intel® 12th Gen Core™ processors, letting you zip through lessons and tutorials effortlessly. Integrated with Intel® WiFi 6 and Bluetooth 5.1 , experience ultra-fast, versatile connectivity to facilitate remote and hybrid classes with ease.
Stability in every lesson
Teach and present without any worry about sudden disruptions. Built with the FinchGuard, a Watchdog timer software, the VPC37-W53-G1 intuitively detects and recovers from system malfunctions seamlessly to maximize productivity.
Stay cool and blaze through classes
Equipped with a thermal control circuit and noise reduction capabilities, the fan within the device will dissipate much more heat in quieter acoustics of under 35 decibels for more conducive and longer lessons.
Boot up with total security
Prevent malicious software and unwanted operating systems from loading during start-up with the optional Secure Boot in the BIOS setting. This stops existing errors from loading and keeps unauthorized personnel from accessing PC settings.
Built-in myViewBoard software
The VPC37-W53-G1 seamlessly integrates with myViewBoard software, offering teachers a wide range of interactive lesson and presentation possibilities. Effortlessly prepare, save, and share class materials across various platforms in an instant.
規格
- 軟體作業系統: Windows 11 Pro
- 系統核心CPU: Intel® Core™ i7-1260P 2.1G Turbo boost 4.7G
顯示卡: Integrated Intel® iris Xe Graphics (96EU)
Total Available Graphics Memory: 32GB
Max Resolution up to 7680x4320@60Hz (DP) - 內建記憶體類型: DDR4 SO-DIMM
容量: 16GB (up to 32GB)
- 儲存空間外觀尺寸: M.2 2280 (22 x 80 mm)
容量: 256GB SSD
介面: PCIE and SATA 3 - INPUTMIC (麥克風): x1
- OUTPUTDisplay Port: x1 (1.4 max. resolution 7860x4320@60Hz)
HDMI: x 1 (2.0 max. , resolution 3840x2160@60Hz)
音訊: x 1 Line out - LANRJ45: x1
- 無線 / 藍牙無線 / 藍牙: Intel® Wi-Fi 6 AX200 802.11 a/b/g/n/ac/ax 2T2R + BT5.1
- USBType A: USB 3.0 x 4
Type C: x 1 (data only) - Bundled Software搭載軟體: myViewBoard for Window
Adobe Reader
BIOS Winflash tool
FinchGuard (Watch Dog)" - 電源電壓: DC 12-19V/ 8A
消耗功率: 96 W (Max) - OPERATING CONDITIONS溫度 (ºC): -5~40°C
濕度: 10% ~ 90% @ 40°C Non-condensing. - 外觀尺寸 (寬 x 高 x 深)實體 (inch / mm): 7.95 x 4.83 x 1.18 in / 202 x 122.6 x 30 mm
外箱 (inch / mm): 10.51 x 7.56 x 2.83 in / 267x 192 x 72mm - WEIGHT淨重 (lb/kg): 1.33lb/0.6kg
毛重 (lb / kg): 2.14 lb/0.97kg - REGULATIONSREGULATIONS: cTUVus, FCC/ICES003, FCC ID/ ICID, TPCH DoC, Packing waste, CA65 DoC, CE EMC, (LVD or CB,CE R&TTE, ErP, RoHS Green BOM & DoC,REACH SVHC,WEEE
- 產品內容產品內容: 1. VPC37-W53-G1
2. Quick Start Guide
