CDE7561T

75” Full HD Commercial LED Display

LCD PANEL
Panel Size: 75"
Type/Tech: TFT LCD Module with LED Backlight
Display Area: 1650.24(H) x 928.26(V) (75.0” diagonal)
Aspect Ratio: 16:9
Native Resolution: 1920 x 1080
Colors: 16.7 million colors (8bits-True)
Brightness: 350 nits (typ.)
Contrast Ratio: 5000:1 Typ.
Response Time: 5ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 30,000 Hours Typ.
Surface Treatment: Anti-Glare coating (7H)
Orientation: Landscape
TOUCH
Type/Tech: IR Recognition
Touch Resolution: 32767 x 32767
Touch Point: 20 points touch, 10 points writing
INPUT
HDMI: x3
RGB / VGA: x3
Audio: x3 PC audio(3.5 mm)
CVBS: x1
RS232: x1
OPS: PC Slot (proprietary)

OUTPUT
RGB / VGA: x1
Audio: x1 Earphone Out
SPDIF: x1
LAN
RJ45: x1
USB
Type A: x3 (USB 2.0 including 2 USB ports in front), x1 (USB 3.0)
Type B: x1 (for touch)
SPEAKERS
10Wx2
COMPATIBILITY
RGB PC/HDMI PC: Up to 1920x1080 @60Hz. Refer to timing table (RGB PC)
CVBS: 480i
HDMI: 480i, 480p,720p, up to 1080p
Embedded Linux OS
4.2.1
Bundle Software
ViewBoard Lite, ViewBoard 2.1
USB SUPPORTED FILE FORMAT
Picture - JPEG, BMP, PNG
Video - Codec: MPEG1, MPEG2, MPEG4, H.264, Xvid
Container: MPG, MPEG, MP4, MKV, TS, TP, TRP, VOB, AVI, RM, RMVB, MOV , DAT, FLV, WMA, WMV
Audio - Codec: MPEG1 layer2, MPEG1 layer3, AAC, AC3, PCM
Container: MP3, WAV, M4A
POWER
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 296W (Typ.) <0.5W (“Off”)
ERGONOMICS
Wall Mount (VESA ): 800 x 400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 69.4 x 41.8 x 3.9 inch/ 1763 x 1062 x 100mm
WEIGHT
Net (lb / kg): 132.28lb / 60kg
PACKAGE CONTENTS
VGA cable(5 meters) / Power cable(3 meters) x 4 / Remote control / USB cable(5 meters) / Audio cable(5 meters) / Touching pen x 3 / User manual CD wizard / RS232 adapter
