VC10

Wireless Presentation Dongle

GALLERY

SPECIFICATIONS

Key Component
Processor: Action Micro AM8251
Wireless Module: RTL8192EU 2.4G 2T/2R
System requiremet
WiFi Display(vPresenter Pro): • w/o smoothly video playback : Celeron 2.0G above CPU
• Video playback smoothly – i5 2.4G CPU with SandyBridge
• iOS 7 and above
• Android 4.0 and above
Wireless Network
Interface: Built-in 802.11 b/g/n 2T2R
Frequency Band: 2.4GHz(2.312~2.472GHz, 2.484GHz)
Data transfer speeds: • 150Mbps (max) @ 20MHz
• 300Mbps (max) @ 40MHz

Wireless Security
Security/ Encryption: WPA2, WPA2-PSK
Video outpur
Support Output Resolution: HDMI: 1080P 24/30/60Hz, 720P24/60Hz , XGA, ,WXGA
Connector
HDMI: • HDMI 1.3 with HDCP(2.0/1.x) / MHL compatible
• MHL 2.0 (just compatible MHL2.0 later)
Network: Wireless(802.11a/b/g/n)2.4G, 2T2R
Power: Type Micro USB B (x1) (for HDMI connecton)
Slide Switch: Switch HDMI & MHL function.
Power
DC: 5V/1A or MHL by switch
Consumption: 5W (Maximum)
No standby mode
Controls
Setitng: Control by virtual remote on APP
Operating Condition
Temperature: 23°F to 113°F (-5°C to 45°C)
Humidity: 0% to 95% Non-Condensing
Altitude: 0 to + 13123 ft
Storage Condition
Temperature: -22°F to 140°F (-30°C to +60°C)
Humidity: 0% to 95% Non-Condensing
Altitude: 0 to + 50033 ft
Dimensions
Physical: 94.3 x 32.34 x12.54 (mm)
Weight
Net: 0.06 (lbs)
Gross: 0.22 (lbs)
User Guide
Language (Print): English (WW)
Language (Digital): English, French and Spanish(VSA)
English, German, Russian and Turkish(VSE)
English and Traditional Chinese(VSI)
Included Accessories
The Top Level Assembly shall consist of :
1.VC10
2.HDMI extender
3.UBA cable (A to micro B)
4.QSG

COMPATIBLE WITH VC10
