CDE7500

75" 4K Ultra HD Presenation Display

  • Pre-installed ViewBoard® Cast and Zoom
  • USB multimedia player
  • Supports HDMI CEC pass-through
  • Flicker-free and Blue Light Filter eye-care technologies
  • HDMI, VGA, RS232, RJ45 input compatibility
Sales Enquiry

OVERVIEW

The ViewSonic® CDE7500 is a 75" 4K Ultra HD display with conferencing capabilities. With features including a razor sharp resolution of 3840 x 2160, ultra wide viewing angles, 2 x 20W speakers, and file sharing software, the display has been designed with the meeting room scenario in mind. The pre-installed Cast content sharing and Embedded Zoom conference software enables multiple users, whether on-site or on-line, to participate in conferences and share content with each other simultaneously, transforming CDE7500 into a dynamic content hub. This display’s integrated quad-core processor and 16GB internal memory allows users to play multimedia content from a USB without the need for a PC, while the HDMI and VGA inputs offer connection with a variety of high definition devices. Flicker-free and Blue Light Filter eye-care technologies provide viewing that is comfortable for the human eye, from start to finish.

ViewBoard® Cast Content Sharing Software

ViewBoard® Cast is a content sharing app for mobile devices that enables 1080p content to be streamed from a user’s device onto ViewBoard® wirelessly or over a cable network.

Zoom

Embedded Zoom is a conferencing app that enables content to be streamed from a user’s devices onto ViewBoard® over the internet or an international wireless services (including cell phones and landlines). It supports up to 10 participants, allowing 4 of the 10 to stream content from their laptop or smart phone.

Integrated USB Multimedia Player

This display features an integrated media player with a convenient USB playback function. Now photos, music, and 1080p video can be quickly displayed on-screen directly from a USB drive – without the need for a PC.

Powerful Dual Speakers for Crystal-clear sound

Its 40W speaker design delivers incredible sound while combining eye-catching multimedia content with high-quality sound effects—creating a lasting audio-visual impression on your audience.

4K Ultra HD Resolution

With four-times the resolution of Full HD, this Ultra HD 3840 x 2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.

HDMI CEC Opens A World of HDMI Possibilities

With HDMI CEC functionality, remote controller signals can be transmitted via HDMI cable to connected HDMI devices. This enables out-of-sight DVD players, sound systems, and other devices to be directly controlled with the display’s remote controller for a wider range of viewing possibilities.

Eye-care technologies for comfort viewing

This display adopts exclusive Flicker-Free and Blue Light Filter eye-care technologies. By nearly eliminating screen flickering at all brightness levels via a constant LED light source and reduced blue light exposure, the display ensures longer viewing time and increased eye comfort for presentation and multimedia experiences – without eye fatigue.

I/O Connectors

  1. Internal Speakers
  2. VESA® Compatible Wall Mount 600 x 400 mm
  3. AC In
  4. Menu Controls
  5. HDMI ports
  6. LAN ports
  7. VGA ports
  8. VGA-AUDIO
  9. AV-OUT
  10. YPbPr/YCbCr IN ports
  11. AV-IN ports
  12. AUDIO-IN ports
  13. USB ports
  14. Headset port
  15. SPDIF port
  16. RS232 IN/OUT port

SPECIFICATIONS


  • LCD PANEL
    Panel Size: 75"
    Type/ Tech: TFT LCD Module with LED Backlight
    Display Area (mm): 1649.66(H) x 927.94(V)
    Aspect Ratio: 16:9
    Resolution: 3840 x 2160
    Colors: 1.07B colors (10bit)
    Brightness: 450 nits(typ.) 400nits(min.)
    Contrast Ratio: 1200:1 (typ.)
    Response Time: 8 ms
    Viewing Angles: H = 178, V = 178 (typ.)
    Backlight: DLED
    Backlight Life: 30,000 Hours
    Orientation: Landscape / Portrait
  • INPUT
    HDMI: x 4
    RGB / VGA: x 1
    Audio: x 1
    CVBS: x 1
    YPbPr: x 1
    RS232: x 1
    OPS: x 1 PC Slot (Intel OPS Standard)
    x1 SDM
  • OUTPUT
    HDMI: x 1 (for one of HDMI1/2/3)
    Audio (Earphone out): x 1
    SPDIF: x 1
    RS232: x 1
