CDE7500

75" 4K Ultra HD Presenation Display

  • Pre-installed ViewBoard® Cast and Zoom
  • USB multimedia player
  • Supports HDMI CEC pass-through
  • Flicker-free and Blue Light Filter eye-care technologies
  • HDMI, VGA, RS232, RJ45 input compatibility

SPECIFICATIONS


  • LCD PANEL
    Panel Size: 75"
    Type/ Tech: TFT LCD Module with LED Backlight
    Display Area (mm): 1649.66(H) x 927.94(V)
    Aspect Ratio: 16:9
    Resolution: 3840 x 2160
    Colors: 1.07B colors (10bit)
    Brightness: 450 nits(typ.) 400nits(min.)
    Contrast Ratio: 1200:1 (typ.)
    Response Time: 8 ms
    Viewing Angles: H = 178, V = 178 (typ.)
    Backlight: DLED
    Backlight Life: 30,000 Hours
    Orientation: Landscape / Portrait
  • INPUT
    HDMI: x 4
    RGB / VGA: x 1
    Audio: x 1
    CVBS: x 1
    YPbPr: x 1
    RS232: x 1
    OPS: x 1 PC Slot (Intel OPS Standard)
    x1 SDM
  • OUTPUT
    HDMI: x 1 (for one of HDMI1/2/3)
    Audio (Earphone out): x 1
    SPDIF: x 1
    RS232: x 1
