ViewBoard IN6501

ViewBoard® 65" 4K Interactive Display

Embrace simplicity and organization with the USB-C one-cable solution
Intuitive user interface and fast app launch for smooth operation
Powered by Android 13

Sales Enquiry

GALLERY

OVERVIEW

The ViewBoard IN6501 is the interactive flat panel that delivers exceptional image quality in 4K UHD, thanks to cutting-edge bonding technology that provides clearer colors, enhanced contrast, and reduced glare. The 40-point touchscreen interface, equipped with Ultra Fine Touch Technology, empowers students and teachers to collaborate seamlessly, using either their fingers or dual-tip pens, for an intuitive pen-on-paper experience. Powerful built-in speakers and a USB-C port sort out for a complete and convenient user experience.

Smooth Writing for Intuitive Collaboration

Designed for sharing ideas and student collaboration, the ViewBoard features 40 touchpoints with Ultra-Fine Touch technology and dual-pen capabilities. Experience an enhanced pen-on-paper writing experience as you alternate between the two pens’ dual-tips to effortlessly switch line color and thickness.

Speakers Deliver Elevated Audio Quality

Captivate students with compelling lessons thanks to the built-in dual 20W speakers. Whether sharing instructional videos, musical content, or delivering listening exercises, the IN6501 brings profound audio depth to create memorable experiences.

SPECIFICATIONS

Display
Panel Size: 65"
Panel Type: TFT LCD Module with DLED Backlight, IPS
Display Area (mm): 1428.48(H) × 803.52(V) (64.5” diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors
Brightness: 450 nits
Contrast Ratio: 1000:1 (minimum) / 1200:1 (typical)
Response Time: 8ms
Viewing Angles: H=178, V=178
Backlight Life: 50,000 Hours
Surface Treatment: Hardness: 9H Anti-glare coating
Orientation: Landscape
Platform
Processor: Quad-core ARM Cortex (A55*4)
RAM: 4GB DDR4
Storage: 32 GB
Touch
Type/ Tech: Ultra Fine Touch Technology
Touch Point: 40 points

INPUT
HDMI: x3 (Frontx1:HDMI2.0 with CEC ; Rearx2 [(HDMI2.0 with CEC/ARC)x1, (HDMI2.0 with CEC)x1]
RGB / VGA: x1
Audio: x1
RS232: x1
OPS: x1 (Optional Intel Standard OPS)
WiFi: x1
OUTPUT
Audio: x1
SPDIF: x1
LAN
RJ45: x1
USB
Type A: USB3.0:Front x2, Rear x2；
USB2.0:Rear x1 (Support OTG)
Type B: USB 2.0:Frontx1, Rear x1
Type C: USB 2.0:Frontx1
SPEAKERS
20W x 2
Embedded OS
Android 13
Special Features
All-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels.
Power
Voltage: 100-240V AC
Consumption: On: 190W ; Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 600*400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1488x897x88(mm)/ 58.80x35.31x3.46(in)
Packaging (inch / mm): 1628x1005x208(mm)/ 64.09x39.57x8.19(in)
WEIGHT
Net (lb / kg): 34.95kg/77.05lb
Gross (lb / kg): 45.55kg/100.42lb
REGULATIONS
BIS
PACKAGE CONTENTS
1. 3m power India power plug x 1
2. 3m HDMI cable x 1
3. 3m Touch USB cable (USB2.0) x 1
4. Touch pen X Stylus x 2
5. RS232 adapter x 1
6. Remote control x 1
7. AAA battery x 2
8. Quick Start Guide with Compliance statement
9. Screw x (wall mount)
10. Clamp x 5
Compatible Slot-in PC
VPCF5-W55-G1 / VPC37-W53-G1 / VPC35-W53-G1

COMPATIBLE WITH VIEWBOARD IN6501

VB-CAM-002

Full HD 1080p All-round Web Camera
