LDS135-151
Foldable 135” All-in-One LED Display
- Pre-assembled kit ready for instant use
- Foldable screen with the movable flight case for easy delivery
- Built-in stand with motorized height adjustment
- Impressive audio from Harman Kardon speakers
- Seamless large display for rental at any event/exhibition
規格
- 規格資訊Screen Size: 135''
顯示區域 (mm): 3000 (H) x 1687.5V)
原始解析度: 1920x1080
Panel Technology: Direct view LED
LED Package Type: SMD 3 in 1
Bonding Wire: Gold
Pixel Pitch (mm): 1.56
Refresh Rate: 4440Hz
Brightness (max.): 600 nits (8 levels adjustable)
Contrast Ratio (typ.): 6000:1
顯示方向: Landscape
Viewing Angles (typ.): H = 160, V = 160
LED Lifetime (typ.): 100,000 Hours
本機儲存空間: Total 64GB
(56GB available storage)
內建作業系統: Android 9.0
支援解析度: VGA(640 x 480) to
1080p(1920 x 1080)
HDTV 相容性: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160P/60Hz
水平頻率: 23-120 kHz
垂直掃描率: 15-135 Hz - 輸入HDMI: x6
(HDMI 2.1 x 1, HDMI 2.0 x 3, HDMI 1.4 x 2)
USB Type A: x3
( USB2.0 x3)
RJ45 Input (Internet): x1
IR in: x1
Wi-Fi Input: 2.4G/5G Hz
USB Type C: x1
(Video input、 Power output (5V/2A)) - 輸出HDMI out: x2
(HDMI 2.0 external x1,internal x1)
喇叭: 20W x2 (Harman Kardon)
耳機輸出孔 (3.5 mm): x1
USB Type A (供電): Shared with USB input
(5V/1.5A x3)
- 調整選項USB Type A (Services): x1(shared with USB A input)
RS232 (DB 9-pin female): x1
IR Receiver: x1 - 其他電源供應電壓: 100-120V/30A~ 50/60Hz or 220-240V/15A~ 50Hz
(vary by country)
電源消耗: 1500W (typ), 2500W (max)
< 0.5W (Sleep), < 0W (Off)
運作時溫度: 0~40℃
LED Module Quantity: 100
Ingress Protection Rating: IP30
淨重: 564 lbs
(253 kg)
Gross Weight: 998 lbs
(453 kg)
Screen Dimensions (WxHxD): 1800x1948x770 mm(min.)
3010x2598x770 mm(max.)
Packing Dimensions (WxHxD): 74.8x80x31.5 inches
(1900x2032x800 mm) - Standard Accessories電源線: x1
LAN Cable (Cat 5A): x1 (5m)
遙控器: x1
快速使用手冊: x1
Spare Parts: LED PCB Unit x7
Maintenance Tool: LD-MK-001 x1 - Optional AccessoriesMaintenance Tool: LD-MK-001
ViewBoard Cast Button(USB-C): VB-WPS-001
ViewBoard Cast Button(USB-A+HDMI): VB-WPS-003
