Archived
VPC25-W53-P1
Slot-in PC for ViewBoard®
- Windows 10 Pro (ViewSonic recommends Windows 11 Pro for business)*
- Ideal Integrated Solution for ViewBoard® Interactive Displays & Commercial Displays
- Powerful Intel® 10th Core Processors
- Improved System Stability, Security, & Thermal Control
SPECIFICATIONS
- SoftwareOperating System: Windows 10 Pro 64 bit (ViewSonic recommends Windows 11 Pro for business)*
- CoreCPU: Intel Core i5-10400T (non vPro) 2.0GHz Turbo boost 3.6GHz
Graphics: Integrated Intel® UHD Graphics 630 Intel H410 chipset - MemoryCapacity: 16GB DDR4
- StorageDimension: M.2 2280 (22 x 80 mm)
Capacity: 256GB SSD
Interface: PCIE and SATA 3 - INPUTMIC(Microphone): x1
- OUTPUTDisplayPort: x 1 (1.4, resolution 3840x2160@60Hz)
HDMI: x 1 (2.0, resolution 3840x2160@60Hz)
Audio: x 1 Line out - LANRJ45: GbE LAN Port
- Wireless / BluetoothIntel® Wi-Fi 6 AX200.NGWG.NV + BT5.2 Module dual band
- USBType A: USB 2.0 x 2, USB 3.0 x 4
Type C: USB 3.2 x 1 (data only) - Bundle SoftwareAdobe Reader / myViewBoard WhiteBoard for Windows / BIOS Winflash tool / FinchGuard (Watch Dog) / Intel Unite
- PowerVoltage: AC 110-240V 50/60Hz
Consumption: 110 W - OPERATING CONDITIONSTemperature (º C): -5°C to 40°C
Humidity: 10% ~ 90% @ 40°C Non-condensing. - DIMENSIONS (W x H x D)Physical (inch / mm): 9.69 x 10.45 x 1.27 inch / 246.2 x 265.4 x 32.2 mm
Packaging (inch / mm): 13.78 x 12.2 x 3.54 inch / 350 x 310 x 90 mm - WEIGHTNet (lb / kg): 4.3 lb / 1.95 kg
Gross (lb / kg): 4.63 lb / 2.1 kg - PACKAGE CONTENTS1. VPC OPS
2. QSG - Disclaimer*Upgrade timing may vary by device. Features and app availability may vary by region. Certain features require specific hardware(see Windows 11 Specifications https://www.microsoft.com/en-us/windows/windows-11-specifications?r=1).
COMPATIBLE WITH VPC25-W53-P1
Enterprise Device Licensing Agreement (EDLA) Certified ViewBoard 65” 4K Interactive Display
Enterprise Device Licensing Agreement (EDLA) Certified ViewBoard 75” 4K Interactive Display
Enterprise Device Licensing Agreement (EDLA) Certified ViewBoard 86” 4K Interactive Display
