PD1611
16'' (15.6'' viewable) Pen Display, can display A4 size electronic documents vertically
스펙
- LCD PanelDisplay Area: 344.232 (W)X195.538 (H) mm
Optimum Resolution: 1366 x 768, 16:9
밝기: 220 cd/m2
대비 비율: 1000 : 1
보기 각도: 130° (V) / 90° (H)
Backlight: LED Light-Bar
표면 처리: 8H tempered glass - 커넥터Video: USB2.0
USB: x 1
힘: Share with USB - TouchTechnology: Electromagnetic Resonance
Touch Pen: Battery-Free
Digitizer Resolution: 5080 LPI
Writing Response: 200 PPS (point per second)
Accuracy: ± 0.5mm (center), ± 2 mm (edge)
Pressure Level: 2048 Levels
Detectable Height: 5 - 10mm above glass
- ERGONOMICs틸트: 11°~85°
- 호환성PC: Windows XP, Windows 7, Windows 8
- 입력Frequency: Horizontal:30-48kHz, Vertical:56-70Hz
- 힘전압: 12V / 2A
소비.: 6.5 W - 작동 조건온도: 32°F to 104°F (0°C to 40°C)
습도: 20% - 80%(Max), Non-Condensation - 치수Physical (in / mm): 15.35” x 11.41” x 0.88” inch , 390 x 290 x 22.35 mm
Box (in / mm): 17.87” x 14.76” x 5.12” inch , 454 x 375 x130 mm - 체중순(lb/kg): 1.88 kg
총중량(파운드/kg): 2.39 kg - WHAT'S IN THE BOX1. Pen Display*1 2. Quick Star Guide *1 3. Driver CD*1 4. USB 2.0 Y-cable*1 5. Adapter*1 6. Replacement tool of Pen tip*1 7. Pen*1 8. Pen tip*3 9. Warranty card*1(VSCN only)*1 10. Pen rope*1 11. Stand 12. User Guide *1 (e-file) *Actual content may differ from market to market
