Pro8530HDL

5,200 Lumens Installation Projector

  • Full HD 1080p resolution
  • 1.07 - 1.71 throw ratio
  • Unique "Flex-In" design flexible integration
  • Top cover design for easy dongle and lamp access
  • PortAll® compartment for wireless dongle

REVIEWS


Viewsonic Pro8530HDL Projector Review

“The bottom line is this model is versatile in supporting the most common methods of control via a network and with the optional adapters can support audio/video networking via HDBaseT or wireless networking from with PCs and mobile devices.”

Read Review

Viewsonic Pro8530HDL Projector Review

“The bottom line is this model is versatile in supporting the most common methods of control via a network and with the optional adapters can support audio/video networking via HDBaseT or wireless networking from with PCs and mobile devices.”

Read Review

Best Recommended Award

“'An Ideal Installation Projector'<br>'utilizing a unique "Flex-In" design, the Pro8530HDL integrates an intuitive form, high flexibility and an easy installation process.'”

SPECIFICATIONS


  • DISPLAY
    Type: TI DMD 0.65
    Resolution: 1920x1080 (Full HD)
    F Stop / Focal Length: 2.54~3.07 / 15.75mm ~ 25.1mm
    Optical Zoom: 1.6X
    Keystone: +/- 30° (Horizontal / Vertical)
    Auto keystone: Yes (Vertical)
    Lens Shift: Yes (7.5% Full high or 15% Half high)
    Display Size: 30" ~ 300"
    Throw Distance: 0.71 m ~ 11.36 m
    Throw Ratio: 1.07~1.71
    Lamp Power: 370W
    Lamp Life (Normal / SuperEco Mode): 2,000 / 2,500 (hours)
    Brightness: 5200 ANSI Lumens
    Contrast Ratio: 5000:1
    Normal / Eco Mode: 36dB / 33dB
    Optical Offset: 115%~130%+-5%
  • AUDIO
    Speaker: 10W Cube x 2
  • INPUT CONNECTIVITY
    HDMI/MHL: x1
    HDMI: x3
    VGA: x2
    S-Video: x1
    Component: x2 (Share with VGA input )
    Composite: RCA x1
    Audio: 3.5mm mini jack x2, RCA(L/R) x1
    USB: Type A x1 (Power Charging) / Mini type B x1 (Maintenance and mouse control) / Micro USB Wire x1 (Power Charging)
    Microphone: Share with Audio in 2 connector
