VPC35-W53-G1 - OPS Slot-in PC

Name: VPC35-W53-G1 - OPS Slot-in PC
SKU: VPC35-W53-G1

| Ficha de dados | Mídia

Adicionar para comparar

Product Overview

The ViewSonic^® VPC35-W53-G1 Windows slot-in PC delivers a full Windows experience for users of ViewSonic ViewBoard^® interactive displays. This slot-in PC module easily plugs into compatible displays and supports up to 5K resolution. With a powerful Intel^® i5 processor, and fast SSD, the VPC35-W53-G1 provides the computing power needed for fast-moving educational or corporate environments. Flexible connectivity options include HDMI, USB 3.0 and Type-C ports, as well as Giga LAN RJ45 and integrated Wi-Fi 6 connection.

Visão geral

Processador Intel poderoso

Equipado com um processador Intel^® i5 , este PC slot oferece desempenho suave e rápido, necessário para computação séria.

Wi-Fi mais rápido

O mais recente padrão WiFi 6 oferece desempenho WiFi incrivelmente rápido com velocidades de Internet de até vários gigabits por segundo.

a diagram showing comparisons between different screen resolutions

Impressionante resolução 5K Ultra HD

With support for resolutions up to 5K, this device enables you to enjoy stunning images on your ViewBoard interactive display.

multiple viewboard displays next to a slot in PC module

Compatibilidade versátil

Based on an industry standardized interface - Open Pluggable Specification, this slot-in computing module is compatible with any OPS-compliant interactive or commercial display.

Prêmios

Especificações

Warranty: 1-year limited warranty on parts, labor and backlight, onsite warranty*
MEMORY: 16GB
Regulations: FCC, FCC ID, cTUVus, CA IC
Recycle/Disposal: Descarte-o de acordo com as leis locais, estaduais ou federais.
Package Contents: VPC35-W53-G1, Antenna x 2
Operating System: Windows® 11 Pro 64 bits
USB Type C: 1
USB 3.0: 4
Control: Power, Reset
Bluetooth: BT 5.1
LAN: 1
Line In: 1
Line Out: 1
HDMI Out: 1
DisplayPort Out: 1
CPU Processor Type: Intel<sup>®</sup> Core™ i5-1240P
CPU Processor Speed: 1.7G Turbo boost 4.4G
Graphics Card: Integrated Intel<sup>®</sup> iris Xe Graphics
Operating System: Windows 11 Pro 64 bit
Power in: DC 12-19V/ 8A
Physical: 7.95 x 4.83 x 1.18 em
Carton (W x H x D): 10.51 x 7.56 x 2.83 em
Net (kg): 0.6
Gross: 0.97
Capacity: SSD de 256GB
Wireless LAN: WIFI 6
Temperature: 23°F to 104°F (-5C to 40C)
Storage Temperature: -4°F to 140°F (-20C to 60C)
Humidity: 10% ~ 90% non-condensing
Altitude: 0 - 5000m above sea level
Physical (in.): 7.95 x 4.83 x 1.18 em
Physical (mm): 202 x 122.6 x 30 mm
Net (lbs): 1.33
Gross (lbs): 2.14
