GD1330
Pen Display
- Accurate and Efficient Writing Experience with 8192 Pen Pressure Sensitivity Level
- Paper-like Texture create Natural and Realistic Experience
- One-cable Solution
- Lightweight, Portable and Effortless to use
- Compatible with Windows 7 or later, Mac OS 10.15 or later
SPÉCIFICATIONS
- LCD PANELDisplay Area : 13.3 inch（294×165mm）
Optimum Resolution: 1920×1080 pixels
Luminosité: 300 cd/m²
Rapport de contraste: 800:1
Backlight: LED light-bar
Angles de visualisation: Horizontal 178°, Portrait 178°
Panel Surface: 8H tempered glass - CONNECTORUSB: Mini HDMI to HDMI / USB Type-C to USB Type-A
USB Type-C to USB Type-C
Alimentation: Bus power, Battery-Free pen - TOUCHTechnology: Electromagnetic Resonance
Touch Pen: Battery-Free
Digitizer Resolution: 1920×1080 Pixels
Writing Response : 266 PPS (point per second)
Accuracy: ±0.25mm
Pressure Level: 8192 Levels
Detectable Height: 15mm above glass
- ERGONOMICSInclinaison: ± 60°
- COMPATIBILITYPC: Windows 7 and above
Mac®: mac OS X 10.15 or higher - POWERCharge Interface: USB-C
Tension: 5V
Consommation: 3W(typ)/ 5W(Max) - OPERATING CONDITIONSTemperature (º F / º C): 32°F to 104°F (0°C to 40°C)
Humidité: 20%-80%(Max), Non-Condensation - DIMENSIONS W x H x D (inch/mm)Physical (in / mm): 13.54 x 8.27 x 0.28 in (344 x 210 x 7 mm)
Box (in / mm): 16.54 x 14.76 x 11.81 in (420 x 375 x 300 mm) - WEIGHTNet (lb / kg): 1.81 lb (0.815kg)
Brut (lb / kg): 3.31 lb.( 1.45kg) - WARRANTY1 Year
- WHAT'S IN THE BOX1. GD1330 x1
2. Stand cover case x1
3. Quick start guide x1
4. Digital pen x1
5. Pen stand x1
6. Pen nib remover x1
7. Pen nibs (Soft) x3 & (Hard) x3
8. Drawing glove x1
9. USB C-C cable (1m) x1
10. USB A-C cable (1m) x1
11. HDMI-mini HDMI cable (1m) x1 - DIMENSIONSPhysique (mm): 344×210×7mm
