Direct View LED
LDP216-251
주요 기능
- Impressively large, bezel-free visual experiences
- All-in-One design without complicated setup
- Real-to-life colors and high brightness
- Immersive audio from built-in Harman Kardon speakers
- Adaptable and flexible to suit any display scenario
- Effortless full-front maintenance
제품 설명
Gaze upon astoundingly lifelike imagery on the minimalistic 2nd Gen 135” ViewSonic® LDP135-151 All-in-One Direct View LED display. The All-in-One modular design offers an effortless installation and maintenance process. This next-generation display is upgraded with advanced features to deliver a spectacular audiovisual experience and user-forward design.Delivering 120% Rec. 709 wide color gamut, lightning-fast 4,440Hz refresh rate, and a peak brightness of 600 nits, every video, presentation, or lecture will be an immersion of real-to-life color and extraordinary detail. The display is also equipped with Harman Kardon speakers, 4K/HDR/HLG support and Frame Interpolation technology for unsurpassable, immersive content delivery. At 25mm slim and lined with a 5mm frameless edge, the sleek display exudes sophistication and elegance in any modern setting. It offers flexibility and adaptability in design – with portrait and landscape installations to complement any space and scenario. The screens can be easily fused together to form an ultra-wide 32:9 video wall to deliver a seamless visual experience in epic proportions. The system control box can also be easily detached to blend into every design.
- Power Switch
- Harman Kardon Speakers
- HDMI Out
- Audio Out
- S/PDIF Out
- IR In
- USB 2.0 (5V/1.5A) x 2
- LAN & Control
- HDMI 2.0 x 2
- HDMI 1.4 x 2
- HDMI 2.1
- RS232
- USB-C (5V/2A)
- USB 2.0 (5V/1.5A)
- IR Receiver
- Menu Control: Brightness Level
- Menu Control: Volume
- Menu Control: Input Source
- Power Button
- Indicator Light
방문
- www.viewsonic.com
-
사양
Screen Size: 216'' 표시면적(mm): 4800 (H) x 2700(V) 기본 해상도: 1920x1080 Panel Technology: Direct view LED LED Package Type: SMD 3 in 1 Bonding Wire: Gold Pixel Pitch (mm): 2.50 Refresh Rate: 4440Hz Brightness (max.): 600 nits (8 levels adjustable) Contrast Ratio (typ.): 6000:1 오리엔테이션: Landscape / Portrait Viewing Angles (typ.): H = 160, V = 160 LED Lifetime (typ.): 100,000 Hours 로컬 스토리지: Total 64GB
(56GB available storage)임베디드 OS: Android 9.0 해상도 지원: VGA(640 x 480) to
1080p(1920 x 1080)HDTV 호환성: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160P/60Hz 수평 주파수: 23-120 kHz 수직 검색 속도: 15-135 Hz -
입력
HDMI: x5
(HDMI 2.1 x 1, HDMI 2.0 x 2, HDMI 1.4 x 2)USB 타입 A: x3
(USB2.0 x3)RJ45 Input (Internet): x1 IR in: x1 Wi-Fi Input: 2.4G/5G Hz USB 타입 C: x1
(Video input、 Power output (5V/2A))HDBaseT: x1
(1080P@100m、4K30Hz@70m) -
산출량
HDMI out: x2
(HDMI 2.0 external x1,internal x1)스피커: 20W x2 (harman kardon) 오디오 출력(3.5mm): x1 USB 타입 A(전원): Shared with USB input
(5V/1.5A x3) -
통제
RJ45 (LAN control): x1 USB Type A (Services): x1(shared with USB A input) RS232 (DB 9-pin female): x1 IR Receiver: x1 -
다른이들
전원 공급 전압: 100-120V/30A~ 50/60Hz or 220-240V/15A~ 50Hz
(vary by country)전력 소비: 2500W (typ), 4000W (max)
<0.5W (Sleep),<0W (Off)작동 온도: 0~40℃ LED Module Quantity: 128 Ingress Protection Rating: IP30(Front) 순 중량: 661 lbs
(300 kg)Gross Weight: 1129 lbs
(512 kg)Screen Dimensions (WxHxD): 189.4x111x1 inches
(4810 x 2820 x 25 mm)Screen Dimensions (WxHxD) with wall mount: 189.4x111x2.2 inches
(4810 x 2820 x 57 mm)Packing Dimensions (WxHxD): 109.4x27.9x37 inches
(2780x710x940 mm) -
STANDARD ACCESSORIES
전원 코드: x2 HDMI 케이블 »: x1(5m) LAN Cable (Cat 5A): x1(5m) IR Extender Cable: x1(3m) 원격 제어: x1 QSG: x1 벽 마운트: x1 Spare Parts: LED PCB Unit x7 Maintenance Tool: LD-MK-001 x1 -
OPTIONAL ACCESSORIES
Maintenance Tool: LD-MK-001 ViewBoard Cast Button(USB-C): VB-WPS-001 ViewBoard Cast Button(USB-A+HDMI): VB-WPS-003
