Klíčové Vlastnosti
  • Expansive 136-inch display with 600 nits brightness and dual 30W speakers delivers vivid visuals and powerful sound for any space
  • Advanced COB technology ensures enhanced durability with water, dust, and impact resistance—ideal for high-traffic professional spaces
  • All-in-One integration simplifies installation by combining power, control, image stitching, and display
  • Energy-efficient design with common cathode LEDs and smart ICs reduces power consumption and supports sustainable operation
  • Smart collaboration tools include PIP/PBP screen-split modes, LAN control, and wireless content sharing via ViewShare and AirSync

LDP136-151C
Produkt Popis
The ViewSonic LDP136-151C is a 136" enterprise-class All-in-One LED Display designed to elevate visual performance for business presentations, corporate communications, and collaborative environments. Featuring Full HD (1080p) resolution, 600 nits of brightness, a 10,000:1 contrast ratio, and dual 30W speakers, it delivers sharp visuals, vibrant color, and powerful sound for impactful presentations. Ideal for mid to large conference rooms, C-level boardrooms, and corporate lobbies, the display is built with Chip-on-Board (COB) technology for enhanced durability against impact, dust, and moisture, achieving IP54 and IK08 protection ratings. All-in-One integration simplifies installation by combining power, control, image stitching, and display, allowing two people to complete setup in under two hours. A 31mm ultra-slim profile and near bezel-free design create a premium aesthetic that complements any professional space. Powered by a common cathode LED design and smart driving ICs, the display reduces power consumption while supporting long-term energy efficiency. Designed for seamless collaboration, it features PIP/PBP screen-split modes, LAN control, and optional wireless content sharing via ViewShare (sold separately) and AirSync—making it a smart, future-ready LED video wall solution for corporate and educational environments.
  1. Speakers
  2. HDMI 2.0 x3
  3. RJ45 (Internet, Control) x2
  4. Audio Out x1
  5. IR Out x1
  6. USB-A (Power) x1
  7. HDMI 2.0 x1
  8. RS232 x1
  9. Audio Out x1
  10. Wireless/ Bluetooth Antenna
  11. USB-C (Data only) x1
  12. USB-A (2.0, 3.0) x2
  13. Keypad
  14. Power Button
  15. IR Receiver
Navštivte nás
  • www.viewsonic.com
  • SPECIFIKACE
    Screen Size: 136"
    Plocha displeje (mm): 3000 (H) x 1687.5(V)
    Nativní rozlišení: 1920x1080
    Panel Technology: Direct view LED
    LED Package Type: Flip Chip COB
    Pixel Pitch (mm): 1.56
    Brightness (max.): 600 nits (100 levels adjustable)
    Contrast Ratio (typ.): 10000:1
    Color Temperature: 3000K -10000K
    Orientace: Landscape
    Viewing Angles (typ.): H = 170, V = 170
    LED Lifetime (typ.): 100,000 Hours
    Místní úložiště: Total 32GB
    (26GB available storage)
    Zabudovaný operační systém: Android 9.0
    Podpora rozlišení: VGA(640 x 480) to 4K(3840 x 2160@60hz)
    Kompatibilita s HDTV: 480p, 576p, 720p, 1080p, 2160p
    Horizontální frekvence: 31K-94kHz
    Vertikální rychlost snímání: 56-85Hz
  • VSTUP
    HDMI: 4
    (HDMI 2.0/HDCP 2.2)
    (internal x3, external x1)
    USB Typu A: 3
    (USB3.0 x1, USB2.0 x2)
    RJ45 vstup: 3
    (internet x2, control x1)
    IR in (3.5mm): 1
    Wi-Fi Input: 2.4G/5G Hz
    USB Typu C: 1
    (data only)
  • VýSTUP
    HDMI out: 1
    (HDMI 2.0/HDCP 2.2)
    (internal x1)
    Reproduktor: 30Wx2
    Audio výstup (3,5 mm): 2
    S/PDIF: 1
    USB typu A (napájení): Shared with USB A input
    (USB 3.0 5V/0.9A x1, USB 2.0 5V/0.5A x1, USB 2.0 5V/2A x1)
    USB Type C (Power): Shared with USB Type C input
    (5V/1A x1)
  • KONTROLA
    RJ45 (LAN control): 1(shared with internet)
    USB Type A (Services): 1(shared with USB A input)
    RS232 (DB 9-pin female): 1
    IR Receiver: 1
  • DALší
    Napětí zdroje napájení: 100-240V ~ 50/60Hz
    (vary by country)
    Power Consumption (W/unit): 400W (typ), 1095W (max)
    < 0.5W (Hibernate)
    Provozní teplota: 0~40℃
    Total LED Module Quantity: 200
    Ingress Protection Rating: IP54(Front)
    Impact Protection Rating: IK08(Front)
    Čistá hmotnost: 372.58 lbs
    (169 kg)
    Gross Weight: 599.66 lbs
    (272kg)
    Product Dimensions (WxHxD): 118.58 x 72.22 x 1.61 inches
    (3012 x 1834.5 x 41mm)
    Product Dimensions (WxHxD) with wall mount: 118.58 x 72.22 x 2.35 inches
    (3012 x 1834.5 x 59.8mm)
    Packing Dimensions (WxHxD): 77.95 x 40.16 x 48.03 inches
    (1980 x 1020 x 1220mm)
  • STANDARD ACCESSORIES
    Napájecí kabel: 1
    LAN Cable (Cat 5E): 1
    IR Extender Cable: 1
    Dálkové ovládání: 1
    Installation Guide: 1
    Nástěnný držák: 1
    Spare Parts: LED module x14
    2 in 1 hub board x1
    Receiving board x1
    Maintenance Tool: LD-MK-004 x1
    LD-MK-006 x1
  • OPTIONAL ACCESSORIES
    Maintenance Tool: LD-MK-004
    LD-MK-006
    Floor Stand: LD-STND-009
