VOT132

DISCONTINUED

VOT132

Click Main Image to Enlarge

$411.00

Out of stock

Features

[DISCONTINUED]Nettop PC Intel Atom 330 (ION) 2GB RAM 320GB SATA HDD Multi-language OS for Win7 Pro 32bit 802.11b/g/n w/o ODD, Black

Select to Compare

Online Merchants

Overview

Overview

Built with the latest Windows® 7 Home Premium OS and Intel® Atom™ 330 Dual Core processor and nVIDIA ION GPU, the ViewSonic VOT132 is ideal for surfing the web, setting up an entertainment hub or home office computing. Save desktop space by attaching the PC Mini to your VESA® ready monitor or use the included trim desktop stand. The eco-friendly design uses up to 80% less energy consumption than standard PCs. ViewSonic PC Mini’s are the smart choice to work, play and connect virtually anywhere.

Key Features:

Intel® Atom™ 330 processor with 2GB memory for efficient computing
nVIDIA MPC7A-10N ION for 1080p playback
320GB SATA Hard Drive
802.11 b/g/n Wi-Fi connectivity
High speed USB 2.0 (x6) back and front locations for easy connecting for peripherals with 5-in-1 Media Card Reader
Windows 7 Home Premium OS Installed
VESA® mounting bracket included - Attach to the back of your display
Green - centric compact design uses less power, cables and plastic

Learn More

Versatile Connectivity & Inputs

In addition to the all-digital HDMI and DVI outputs and convenient 5-in-1 memory card reader, the ViewSonic VOT132 PC mini comes with six USB 2.0 ports (two on the front panel, four on the back) for keyboards, mice, storage devices, card readers, joysticks, digital cameras and anything USB. We know you like good music, so we gave the VOT132 the S/PDIF high-end sound output through coaxial cable and fiber optics

Space Saving Design

The VOT132 PC mini is just about half the size of a sheet of paper. It takes up very little desk real-estate and can be installed behind ViewSonic flat-panel monitors (or other VESA-compliant models) with the VESA mounting kit. Of course, you can also stand it up next to your ViewSonic monitor to show everyone how smart and eco-friendly you are.

Expand & Burn

If there’s always a need to burn CD or DVD discs, you may want to add the optional VDD-100 8x DVD Super Multi drive module to your VOT132. The optional module has a matching exterior and can be attached to the VOT132 via magnetic contacts for an all-in-one look. It’s convenient and it takes up no additional desk space

nVIDIA ION - Big Graphics, Small Form Factor

NVIDIA® ION™ graphics processors turn up the visuals on compact, low-power PCs with performance up to 10X faster than similar systems. When combined with a low-power CPU like an Intel Atom, ION graphics processors transforms the PC into a premium experience. Key features include: Full 1080p HD video with true-fidelity 7.1 audio, Premium DirectX 10 graphics and a premium Windows experience with Windows 7

Windows® 7 Home Premium Installed

Microsoft's new Windows 7 OS boasts tons of new features designed to simplfy everyday tasks, work the way you want it to work and make new possibilities in just a click's reach. "Your PC, simplified."

Intel Atom Processor

The Intel® Atom™ 330 is an efficient low power-using dual core processor that is still solid on performance. Utilizing Intel® Hyper-Threading Technology, Intel® Atom™ processors optimize performance in small form factor devices even when running multiple, resource hungry applications

Green Centric

The green energy-saving design makes the PC mini VOT132 quieter than a notebook and is one of the coolest running desktops. Running on the Intel Atom processor requires less power usage. Elimnating the need for a bulky tower PC saves plastic. ViewSonic designs PCs that are also easy to recycle

Product Specifications

Dimensions (WxHxD): 7.48" x 0.98" x 5.32" (190mm x 135mm x 24mm)
Weight
- Net: 0.99 lb. (0.5 kg)
- Gross: 3.1 lb. (1.4 kg)

Check Out Other ViewSonic Products

Specs

CORE

CPU Processor Type
Intel® Atom™ 330

CPU Processor Speed
1.6GHz Dual Core, FSB 533MHz

Chipset
NVIDIA® MCP7A-ION

SOFTWARE

Operating System
Windows 7 Professional

POWER

Power Adapter
19V DC; 65W adapter

Power Cord
3-pin AC Plug

OPERATING CONDITIONS

Temperature
32-104°F (0-40°C)

Humidity
15-80% (non-condensing)

Altitude
0-10,000 ft. (3048 m)

DIMENSIONS (WxHxD)

Physical
7.48" x 0.98" x 5.32" (190mm x 135mm x 24mm)

Carton (W x H x D)
12.2" x 10.6" x 2.7" (310mm x 268mm x 65mm)

WEIGHT

Net
0.99 lb. (0.5 kg)

Gross
3.1 lb. (1.4 kg)

HARD DRIVE

Capacity
320GB SATA

Optical Drive
DVD and CD +/– RW Super Multi drive (optional VDD100)

COMMUNICATION

Ethernet LAN
10/100/1000 Gigabit Ethernet

Wireless LAN
802.11b/g/n

Vesa Mount

75mm x 75mm, 100mm x 100mm

Warranty

1-year limited warranty

MEMORY

2GB DDR2 SDRAM

INPUT/OUTPUT

USB 2.0 (x6), DVI, HDMI, SPDIF/Mic In, SPDIF Out, RJ45 Gigabit Ethernet LAN, Headphone jack

SECURITY

N/A

Regulations

UL, cUL, CE, FCC-B, RoHS, EPEAT Silver, ENGERY STAR®

Recycle/Disposal

Please dispose of in accordance with local, state or federal laws.

PACKAGE CONTENTS

VOT132, power cord, power adapter, stand, VESA® mounting bracket, Driver CD, Quick Start Guide

OPTIONAL ACCESSORIES AVAILABLE

N/A

Downloads

Specifications

User Guides

Drivers

VOT132 Atheros Wireless Driver XP Download Driver
